Working weight

37,650 kg

Bucket capacity

1.71 ~ 1.9 m3

engine model

DC09

Walking speed (1 speed / 2 speed)

4.9 / 2.9 km / hr

Swivel torque

12,020 kgf.m

Bucket digging force

26 Ton

Stick digging force

20.4 Ton

Maximum digging height

10,100 mm

Maximum dumping height

7,180 mm

Maximum digging depth

7,135 mm

Maximum vertical digging depth

3,810 mm

Maximum digging radius

10,845 mm

full length

11,380 mm

Full width

3,350 mm

Full height (to the top of the boom)

3,630 mm

Full height (to the top of the cab)

3,200 mm
