Working weight

30,220 kg

Bucket capacity

1.45 ~ 1.6 m3

engine model

DL08

Walking speed (1 speed / 2 speed)

5.7 / 3.2 km / hr

Swivel torque

11,760 kgf.m

Bucket digging force

18.7 / 19.8 Ton

Stick digging force

13.1 / 13.9 Ton

Maximum digging height

10,315 mm

Maximum dumping height

7,303 mm

Maximum digging depth

7,275 mm

Maximum vertical digging depth

4,907 mm

Maximum digging radius

10,702 mm

full length

10,615 mm

Full width

3,200 mm

Full height (to the top of the boom)

3,515 mm

Full height (to the top of the cab)

3,031 mm
